10. Specifications
Display 4 inch TFT Color LCD
Numbers of pixel 272 x 480
Numbers of color indicated Max. 10 colors
Power Supply Size AA battery 8 pcs. or 11-14VDC
Power Consumption Approx. 3W
Dimension (Display unit) 173 (H) x 173 (W) x 78 (D) mm
Weight (Display unit) Approx. 0.7kgs
Frequency 200kHz
Output Power 100W
Display
Displayed Range 0-3m 〜 0-300m
Auto Range OFF/ON
Auto Gain OFF/LOW/MID/HIGH
Expansion Expansion(OFF/Bottom Lock/Auto Exp/Manual Exp
Expansion Rate x2/x4/x8
A-Mode OFF/ON
Fish Alarm OFF/ON
Fish Mark OFF/ON
Depth Alarm OFF/In Range/Out Range
Water Temp. Alarm OFF/In Range/Out Range
Sweep Speed 5 speeds (S, 1, 2, 3, 4) + STOP
Background Color 3 Colors (Blue, White and Black)
Color Configuration 4 kinds
Back Light 5 ranks
Voltage Indication
Water Temp. Indication
Depth Unit m/ fe/ fa/ Br
Bottom Nature Distinction OFF/ON
Clean Echo OFF/LOW/HIGH
Pulse Length Short/Medium/Long
Functions
Lantern Mode
Specifications and appearance are subject to change without prior notice due to
improvement.
