113
TECHNICAL INFORMATION
MODEL BF250A
Description code BBJJ
Type
LA
LW
XA
XW
XC
XCA
XCW
XCC
XXA
XXW
XXC
XXCA
XXCW
Overall length 36.2 in (920 mm)
Overall width 24.6 in (625 mm)
Overall height 69.3 in
(1,760 mm)
74.3 in
(1,887 mm)
79.3 in
(2,014 mm)
Transom height
(when transom angle
is 12°)
20.0 in
(508 mm)
25.0 in
(635 mm)
30.0 in
(762 mm)
Dry mass [weight]* 613 lbs
(278 kg)
626 lbs
(284 kg)
635 lbs
(288 kg)
Rated power 186.4 kW (250 HP)
Full throttle range 5,300 – 6,300 rpm
Engine type 4 stroke OHC VTEC 6-cylinder (V6)
Displacement
218.6 cu-in (3,583 cm
3
)
Spark plug gap 0.039 – 0.043 in (1.0 – 1.1 mm)
Starter system Electric starter
Ignition system Fully transistorized, battery ignition
Lubrication system Trochoid pump pressure lubrication
Specified oil Engine: API standard (SG, SH or SJ oil)
SAE/FC-W 10W-30
Gear case: API standard (GL-4) SAE 90
Hypoid gear oil
Oil capacity Engine: 8.0 US qt (7.6 L)
without oil filter change
8.2 US qt (7.8 L)
with oil filter change
Gear case: 1.55 US qt (1.47 L)
CARB star label ULTRA · LOW EMISSION
D.C. output 12 V – 60 A
Cooling system Water cooling with thermostat
Exhaust system Water exhaust
Spark plugs ZFR6K-11E (NGK)
Fuel pump Low pressure side: mechanical type
High pressure side: electrical type
Fuel Unleaded gasoline
(86 pump octane or higher)
Gear change Forward-Neutral-Reverse (dog type)
Steering angle 30° right and left
Tilt up angle
(when transom angle is
12°)
Stageless (68°)
Trim angle
(when transom angle is
12°)
– 4° to 16°
* Without battery cable, with propeller
Honda outboard motors are power rated in accordance with NMMA procedures and using the ICOMIA standard 28/23.
Specifications
31ZX26040.book Page 113 Friday, July 25, 2014 5:14 PM
