35
CONTROLS AND FEATURES
Rev Limiter
The engine is equipped with a rev
limiter to prevent the possibility of
mechanical damage from excessive
engine speed.
The rev limiter may be activated
during operation, limiting engine
speed, if the outboard motor is
trimmed or tilted up excessively, or
when propeller ventilation occurs
during a sharp turn.
If the rev limiter is activated, check
the trim angle of the outboard motor.
Check to see if the correct propeller is
installed.
Anodes
The anodes are made of a sacrificial
material that helps to protect the
outboard motor from corrosion.
There are two anodes on the gear
case, one on the stern bracket and
four small anodes in the water
passages of the engine block.
Fuel Priming Bulb
A priming bulb is built into the fuel
hose that connects the fuel tank to the
outboard motor.
Before starting the engine, hold the
priming bulb up in the direction of the
arrow; then squeeze the priming bulb
until it feels firm. This will ensure
that fuel is supplied to the engine
(p. 39).
ANODE
(each side)
ANODE
(stern bracket)
UP
OUTLET END
(outboard motor side)
PRIMING BULB
INLET END (tank side)
31ZX26040.book Page 35 Friday, July 25, 2014 5:14 PM
