9. Lower the front wheel on the ground.
10. Apply the brake lever several times. Then,
pump the fork several times.
11. Retighten the left axle pinch bolts.
Torque: 23 N·m (2.3 kgf·m, 17 lbf·ft).
12. Raise the front wheel off the ground
again, and check that the wheel rotates
freely after you release the brake.
13. Check the clearances between each
surface of the brake disc and the brake
caliper body (not the brake pads) are
symmetrical.
If the clearances are not symmetrical,
loosen the left axle pinch bolts and pull
the left fork outward or push inward to
adjust the clearance.
14. Lower the front wheel on the ground.
15. Remove the protective tape or cloth.
If a torque wrench was not used for
installation, see your dealer as soon as
possible to verify proper assembly.
Clearance
Brake caliper
body
Brake disc
