Rear Wheel
Removal
1. Support your motorcycle securely and
raise the rear wheel off the ground using
a maintenance stand or a hoist.
2. Loosen the rear axle nut and turn the
adjusting bolts so the rear wheel can be
moved all the way forward for maximum
drive chain slack.
3. Remove the rear axle nut/washer.
Adjusting bolt
Rear axle nut
4. Remove the drive chain from the rear
wheel sprocket by pushing the rear wheel
forward.
5. Remove the rear axle shaft.
Adjusting bolt
Rear axle nut
Drive chain
continued
