Instruments & Controls
14
Indicators & Displays
The indicators and displays on your ATV keep you informed, alert
you to possible problems, and make your riding safer and more
enjoyable.
Refer to the indicators frequently. Their functions are described on
the following pages.
(1)
(5)
(1) neutral indicator
(3)
(8) (7) (6)
(4)(2)
(2) reverse indicator
(3) differential lock indicator
(5) high coolant
temperature indicator
(6) PS (Electric Power
Steering) indicator
(TRX500FM2 only)
(4) PGM-FI indicator (7) multi-function display
(8) mode select button
19 TRX500FM1 FM2 (U)-32HR4A40.backup.book Page 14 Wednesday, April 18, 2018 3:36 PM
