Honda FOURTRAX - Parking Brake;Reverse Lever (P;R Lever)

Instruments & Controls
45
Controls & Features
The P/R lever (1) on the rear brake lever/parking brake lever (2) is
used to apply the parking brake or to shift the transmission into
reverse.
Parking Brake/Reverse Lever (P/R Lever)
(2)
(1)
(1) P/R lever
(2) rear brake lever/parking brake lever
