Honda FOURTRAX - Odometer; Tripmeter

Instruments & Controls
27
Indicators & Displays
The odometer (1) registers total distance traveled in mileage while the
ignition switch is ON (q) with the “ODO” mark (2). The odometer
locks at 999,999 when the readout exceeds 999,999.
The tripmeter (1) shows mileage per trip since you last reset the
tripmeter while the ignition switch is ON (q) with the “TRIP” mark
(2). The tripmeter returns to 0.0 when the readout exceeds 999.9. To
reset the tripmeter to zero, press the mode select button (3) and
hold it in for at least 2 seconds in the tripmeter mode.
Odometer
Tripmeter
(2) (1)
(1) odometer (2)“ODO” mark
(1)(3)
(1) tripmeter (3) mode select button
(2) “TRIP“ mark
(2)
