Honda FOURTRAX - Front Brake Lever; Rear Brake Lever;Parking Brake Lever; Rear Brake Pedal

Instruments & Controls
44
Controls & Features
The front brake lever is used to slow or stop your ATV. To operate,
pull the lever. For information on braking techniques, see page 87.
The rear brake lever/parking brake lever is used to slow or stop your
ATV. To operate, pull the lever. For information on braking
techniques, see page 87.
The rear brake pedal is used to slow or stop your ATV. To operate,
depress the pedal. For information on braking techniques, see
page 87.
Front Brake Lever
Rear Brake Lever/Parking Brake Lever
Rear Brake Pedal
