Instruments & Controls
43
Controls & Features
The throttle controls engine rpm (speed). To increase engine rpm,
press the throttle lever (1) with your thumb. To reduce engine rpm,
release pressure on the throttle lever. The throttle will automatically
return to the closed position (engine idle) when you remove your
thumb.
Throttle Lever
RIGHT HANDLEBAR
(A)
(1)
(1) throttle lever (A) to open the throttle
19 TRX500FM1 FM2 (U)-32HR4A40.backup.book Page 43 Wednesday, April 18, 2018 3:36 PM
