Instruments & Controls
31
Indicators & Displays
The maintenance tripmeter (1) shows mileage to maintenance while
the ignition switch is ON (q) with the maintenance minder indicator
(2).
The maintenance hour meter (3) shows remaining time to
maintenance while the ignition switch is ON (q) with the
maintenance minder indicator.
The maintenance tripmeter decreases from 1,000 km (600 miles)
after reset. The maintenance hour meter decreases from 100 hour
after reset.
Initial setting of the maintenance tripmeter is 150 km (100 miles).
Initial setting of the maintenance hour meter is 20 hour.
Maintenance Tripmeter/Maintenance Hour meter
(1)
(1) maintenance tripmeter
(2) (3) (2)
(3) maintenance hour meter
(2) maintenance minder
indicator
19 TRX500FM1 FM2 (U)-32HR4A40.backup.book Page 31 Wednesday, April 18, 2018 3:36 PM
