CHAPTER 7 - ENGINEER'S OPERATING
INSTRUCTIONS
3. UNLOCKING THE ENGINEERING CARD
To unlock the Engineering Card, plug the Engineering Key into the
Engineering Card front panel socket. The Engineering Card Unlocked
LED ( ) will illuminate to indicate that it is unlocked.
External Engineering
Engineering Key
Port
Note: Inserting and then removing the Engineering Key resets the
Engineering Card communications failure warning indication.
