8 - 8
MAN0443.P65 Issue 13 Aug 04 5701 Control System
05701-M-5001 A02279
CHAPTER 8 - SPECIFICATION
Push-Button:
Operating: Up ( ) and Down ( ).
Reject ( ) and Accept ( ).
Print (Up and Down together).
Functions: Bead mA Alarms
Zero Signal
Span 1st Span
Inhibit Clock
Power Consumption: 1.5W (typical).
DC Supply: 18V to 32V dc.
Dimensions: Height: 112mm.
Width: 25mm.
Depth: 170mm.
Weight: 152g.
5.7 DC Input Card
DC Supply: 18V to 32V dc.
Dimensions: Height: 112mm.
Width: 25mm.
Depth: 102mm.
Weight: 129g.
Fuse Rating: 10A Anti-surge. 1˘ x ˘ inches.
Field Terminals: 2.5mm˝ (14 AWG).
6. CABINET ASSEMBLIES
Material: Mild steel.
Weight: 8-way: 10.0kg
16-way: 13.5kg.
Gland Entries: Knockout.
8-way 2 x M256 x PG11
8 x M202 x PG16
16-way 3 x M25 10 x PG11
16 x M20 4 x PG16
