BENDIX/KING RDR 2000
Page 1-6 00643I05.TDC Rev 7, July/2002
CM 2000 CONFIGURATION MODULE (Included in Installation Kit)
KMD 540 MULTI-FUNCTION DISPLAY
TSO COMPLIANCE: See Appendix E
PHYSICAL DIMENSIONS:
Height: 2.10 in. (5.33 cm)
Width: 1.60 in. (4.05 cm)
Length (w/connector): 2.10 in. (5.33 cm)
Length (w/o connector): 0.85 in. (2.16 cm)
WEIGHT: 0.10 lb. (.046 kg)
TEMPERATURE:
-55
°
to +70
°
C.
ALTITUDE RANGE: 0ft to 55,000 ft.
POWER REQUIREMENTS: Supplied by ART 2000
TSO COMPLIANCE: TSO C113
Display functionality of C110a
ENVIRONMENTAL CERTIFICATION: See TSO Appendix, Environmental
Qualification Forms
TEMPERATURE RANGE:
-20
°
C to +70
°
C
ALTITUDE: 35,000 ft.
PHYSICAL DIMENSIONS: Refer to KMD 550/850 Installation Manual
(P/N 006-10608-XXXX)
WEIGHT: Refer to KMD 550/850 Installation Manual
(P/N 006-10608-XXXX)
COOLING REQUIREMENTS: No external forced air cooling needed. All re-
quired cooling provided by internal fan.
INPUT POWER REQUIREMENTS: 10 to 33 V DC,
20 watts nominal, 40 watts maximum
LIGHTING POWER +28 VDC or +14 VDC or + 5 VDC or 5 VAC
MOUNTING Panel mounted with Honeywell supplied
mounting rack.
