BENDIX/KING RDR 2000
Rev 7, July/2002 00643I05.TDC Page 1-7
KAC 501 WEATHER RADAR MODULE
IN 182A COLOR RADAR INDICATOR
TSO COMPLIANCE: Display functionality of C63c
ENVIRONMENTAL CERTIFICATION: See TSO Appendix, Environmental
Qualification Forms
PHYSICAL DIMENSIONS:
Length:
Width:
7.474 in. (18.983 cm.)
5.047 in. (12.819 cm.)
WEIGHT: Included in unit weight per installation draw-
ing, figure 2-42
POWER REQUIREMENTS: Supplied by KMD 540 base unit
TSO COMPLIANCE: TSO C63b, Class 7, DO-173
DO-160A Env Cat
A1B1/A/PKS/XXXXXXABABA
TEMPERATURE RANGE:
-20
°
C to +55
°
C
ALTITUDE: 25,000 ft. unpressurized
WEIGHT:
Indicator: 8.9 lb. (4.0 kg.)
Mounting Tray: 0.4 lb. (0.18 kg.)
Connector Kit (RS 181A/IN 182A): 0.3 lb. (0.14 kg.)
OVERALL DIMENSIONS:
Height: 4.11 in. (10.44 cm.)
Width: 6.41 in. (16.28 cm.)
Length (including connector): 12.75 in. (32.38 cm.)
POWER REQUIREMENTS: 28 Vdc @ 2.0 amps continuous
Panel Lighting: 14 Vdc @ 1mA
28 Vdc @ 264mA
5 Vac @ 1mA
