BENDIX/KING RDR 2000
Page 1-8 00643I05.TDC Rev 7, July/2002
METAL FLAT PLATE ANTENNAS
WEATHER DISPLAY COLORS:
Black: No Return
Green: Rainfall up to 0.16 in./hr. (4mm./hr.)
Yellow: Rainfall from 0.16 to 0.48 in./hr. (4 to 12mm./
hr.)
Red: Rainfall from 0.48 to 2 in./hr. (12 to 50mm./hr.)
Magenta: Rainfall of 2 in./hr. (50mm./hr.) and over
DISPLAY RANGE/RANGE MARKS: (NM) 10/2.5, 20/5, 40/10, 80/20, 160/40 and 240/60
DISPLAY STORAGE: Digital Memory
DISPLAY TYPE: X-Y raster scan
SELF TEST CAPABILITY: TST position on indicator selects test pattern.
WEATHER DATA INPUT: ARINC 453 bus, ARINC 708 data word
CONTROL DATA OUTPUTS: ARINC 429 characteristic
TSO COMPLIANCE: See Appendix E
ALTITUDE: 55,000 ft. unpressurized
WEIGHT:
10-inch antenna: 0.66 lb. (0.30 kg.)
12-inch antenna: 0.95 lb. (0.43 kg.)
OVERALL DIMENSIONS:
10-inch antenna 9.90 in. (25.15 cm.)
12-inch antenna 11.88 in. (30.18 cm.)
GAIN (min.):
10-inch antenna: 25.7 dB
12-inch antenna: 26.7 dB
VSWR (max.): 1.4:1
BEAMWIDTH:
10-inch antenna:
10
°
12-inch antenna:
8.1
°
