BENDIX/KING RDR 2000
Page 1-10 00643I05.TDC Rev 7, July/2002
1.4.5.1 ART 2000 Installation Kit
The Installation Kit (050-03088-0000) for the ART 2000 Antenna/ Receiver/Transmitter contains
the following parts:
1.4.5.2 IN 182A Installation Kit
When installing the IN 182A, it is necessary to use a connector kit (050-03291-0000) and a mount-
ing tray (047-07535-0000). The contents of connector kit is as follows:
1.4.5.3 KPA 900 Configuration Module Programmer Kit
When installing the RDR 2000 with The KMD 850, Radar indicator, EFS 10 or an EFIS 40/50 in-
stallation with software 08 or lower, it is necessary to use the KPA 900 Configuration Module Pro-
grammer Kit (P/N 050-03311-0002) to program the Configuration Module with the desired param-
eters for that installation. To obtain the programmer kit and software, order the following kit which
contains the items listed:
P/N DESCRIPTION UM
QT
Y
VENDOR PART NUMBER
030-01157-0011 SOCKET CRMP 20G EA 60 Positronic FC6020D-14
030-01171-0000 CONNECTOR S‘UB-D HSG 9S EA 1 Positronic RD09F00000-782.0
030-01176-0010 CONNECTOR SUB-D HSG 50S EA 1 Positronic RD50F0000X-782.0
030-01428-0006 EMI HOOD W/LOCK 50P EA 1 Positronic D50000GVLO-923.15
030-02351-0000 HOOD/LVR ASSY ST E EA 1 Positronic D9000JVLO-476
071-00097-0100 CM 2000 CONFIG MODULE EA 1 Honeywell
089-06494-0005 SCR SHC 8-32X5/16 EA 6 Honeywell
P/N DESCRIPTION UM
QT
Y
VENDOR PART NUMBER
030-01157-0011 SOCKET CRMP 20G EA 37 Positronic FC6020D-14
030-01175-0000 CONNECTOR S‘UB-D HSG 37S EA 1 Positronic RD37F00000-782.0
030-01428-0004 EMI HOOD W/LOCK 37P EA 1 Positronic D37000GVLO-923.15
P/N DESCRIPTION UM -0000 -0001 VENDOR PART NUMBER
006-05392-0000 OPERATOR’S GUIDE EA 1 1 Honeywell
050-03281-0000 CONFIG MODULE PROGRAMMER EA 1 1 Honeywell
222-00366-0002 KPA 900 PROGRAM EA - 1 Honeywell
