BENDIX/KING RDR 2000
Rev 7, July/2002 00643I05.TDC Page 2-47
FIGURE 2-26 ART 2000 PINOUT DIAGRAM (CONT).
P5001 I/O SIGNAL NAME
24 NO CONNECTION
25 NO CONNECTION
26 NO CONNECTION
27 NO CONNECTION
28 NO CONNECTION
29 NO CONNECTION
30 NO CONNECTION
31 I RT #1 ON/OFF (ON=GND)
32 I RT #2 ON/OFF (ON=GND)
33 I RT #3 ON/OFF (ON=GND)
34 I +28 VDC AIRCRAFT POWER
35 I +28 VDC AIRCRAFT POWER
36 POWER AND CHASSIS GROUND
37 POWER AND CHASSIS GROUND
38 CALIBRATION LIGHT (MAINTENANCE ONLY)
39 SPARE
40 I GYRO REFERENCE HI
41 GYRO REFERENCE COMMON
42 O ARINC 453 DATA (A)
43 O ARINC 453 DATA (B)
44 O +5 VDC CONFIGURATION MODULE VOLTAGE
45 O CONFIGURATION MODULE CLOCK
46 O CONFIGURATION MODULE CHIP SELECT 1
47 O CONFIGURATION MODULE CHIP SELECT 2
48 O DATA TO CONFIGURATION MODULE
49 I DATA FROM CONFIGURATION MODULE
50 CONFIGURATION MODULE GROUND
