BENDIX/KING RDR 2000
Rev 7, July/2002 00643I05.TDC Page 2-49
FIGURE 2-27 IN 182A PINOUT DIAGRAM (CONT).
P2001 I/O SIGNAL NAME
23 I EXT DRIVE INPUT, BLUE +
24 I EXT DRIVE CONTROL INPUT, RED CNT +
25 I EXT DRIVE CONTROL INPUT, GR
EEN CNT +
26 I EXT DRIVE CONTROL INPUT, EN EXT
27 O 429 CONTROL BUS 1A
28 I EXT DRIVE INPUT, GREEN -
29 LIGHTING RETURN LO
30 I +28
VDC LIGHTING
31 O RT ON
/OFF
32 I CM
/NAV SENSE
33 I IU ENABLE
34 I IU LOAD
35 I EXT DRIVE CONTROL INPUT, SHLD GND
36 I LB BUFF
37 I +28 VDC POWER IN
To Next Page
