10 DACT-E3 Product Installation Document — P/N 9000-0581:J6 12/16/2019
4.2.2 Custom Formats
The DACT-E3 can be configured to allow each SLC device to report a unique 3-digit code by selecting the Custom DACT
Reporting Feature. The user must specifically enable this feature through configuration programming by using
CAMWorks™. If you enable the Custom DACT Reporting feature, the system uses the Custom codes or optional fields. The
system substitutes the custom formats or optional fields in place of the standard codes. To enable this feature, each ILI-MB-
E3, ILI-S-E3 or SLP-E3 must have V1.3-806 or higher ILI Firmware installed. This feature is also available for the ILI95-
MB-E3, ILI95-S-E3 or SLP-E3. For information on the DACT-E3 Contact ID Event Reporting Codes for Custom Formats,
refer to Table 4.2.2.1. Figure 4.2.2.1 illustrates an example of the DACT Contact ID Reporting Codes for Custom formats
used to configure the following types of systems.
Figure 4.2.2.1 Example of the DACT-E3 Contact ID Event Reporting Codes for Custom Formats
..
For Contact ID and SIA Formats:
GG
= In standalone systems, the group number assigned to the device, 00-99.
= In networked systems, the node number where the device is located, 00-64 (000-122 in multi-ring networks).
0G = In only multi-ring systems, represents the 100s digit of the node address.
For Contact ID and SIA Formats: (Continued)
T
= Type of device or event causing the event to be reported.
0 = Any Device not listed below
1 = General Alarm Device
2
= Manual Station Alarm
3 = Supervisory Device (Non-latching)
4 = Supervisory Device (Latching)
5
= Waterflow (Non-silenceable)
6 = Smoke Alarm
7 = Non-reporting Device
8 = Multi-level Device
9 = CO/Gas Alarm Device
Note: Special AMM/PIDs include the following functions: Reset Switch, Silence Switch, Drill Switch, Alarm Acknowledge Switch,
Trouble Acknowledge Switch.
NOTE: To use the Custom DACT Reporting Feature, all ILI-MB-E3, ILI-S-E3 and SLP-E3 nodes on the network
must have V1.3-806 ILI Firmware installed as the minimum requirement. For additional information, refer to the
CAMWorks Online Help.
Table 4.2.1.1 DACT-E3 Contact ID Event Reporting Codes for Standard Formats
STANDALONE SYSTEMS
CONTACT ID FORMAT
EXAMPLE
NOTE: Group Numbers are
truncated to range [00-99].
[1]=New Event
[3]=Restoral
Event Type
New Event
1
[R] [EEE] [GG] [UUU]
Fire Alarm
110 00
095
Group 00
Group
Number
C O N TA C T ID FO R M A T
Custom Device ID
SINGLE-RING
NETWORKED SYSTEMS
CONTACT ID FORMAT
EXAMPLE
1
Fire Alarm
110 09
New Event
C O N TA C T ID FO R M A T
MULTI-RING
NETWORK SYSTEMS
CONTACT ID FORMAT
EXAMPLE
[1]=New Event
[3]=Restoral
Event Type
New Event
1
[R] [EEE] [NN]
Fire Alarm
110 09
Node
Number
C O N TA C T ID FO R M A T
Node 09
or 109
Node 09
[1]=New Event
[3]=Restoral
[R] [EEE] [NN]
Event Type Node
Number
Custom ID 095
500
Custom ID 500
[UUU]
Custom Device ID
[UUU]
Custom Device ID
880
Custom ID 880
NOTE: Node Num bers above 99
are truncated to range [00-99].
