Honeywell Eclipse MS5145 User Manual

22
Design Specifications
Operational
Light Source:
Visible Laser Diode (VLD) @ 650 nm
Laser Power: Less than 1.0 mW average
Embedded Laser:
Max Power: 10 mW
Wavelength: 650 nm
Depth of Scan Field: 0 mm – 140 mm (0" – 5.5") 0.33 mm (13 mil) Bar Code
Scan Speed: 72 ± 2 scan lines per second
Scan Pattern: Single scan line
Minimum Bar Width: 0.089 mm (3.5 mil)
Decode Capability:
Autodiscriminates all standard bar codes. For other
code types, call a customer service representative.
System Interfaces:
RS232, Keyboard Wedge, USB, RS485, Stand Alone
Keyboard
Print Contrast: 35% minimum reflectance difference
No. Characters Read:
Up to 80 data characters. The maximum number will
vary based on symbology and density.
Roll, Pitch, Yaw: 38°, 67°, 52°
Beeper Operation: 7 tones or no beep
Indicators (LED):
Red = good read
Green = laser on, ready to scan
Mechanical
Length: 170 mm (6.7")
Width
Head: 63 mm (2.5")
Handle: 39 mm (1.5")
Height
Head: 35 mm (1.4")
Handle: 31 mm (1.2")
Weight: 100.8 g (3.56 oz)
Specifications subject to change without notice.

Honeywell Eclipse MS5145 Specifications

General

Scan Pattern	Single Line
Light Source	650 nm visible laser diode
Scan Speed	72 scan lines per second
Interface	USB, RS232, Keyboard Wedge, IBM 46xx (RS485)
Weight	100 g (3.5 oz)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 60°C (-40°F to 140°F)
Humidity	5% to 95% relative humidity, non-condensing
Drop Resistance	Designed to withstand 1.5 m (5 ft) drops
Scan Rate	72 scan lines per second
Decode Capability	1D barcodes
Electrical Specifications	Input Voltage: 5 VDC ± 0.25 V
Regulatory Compliance	CE, FCC, RoHS
