Honeywell Eclipse MS5145 User Manual

2
Basic Kit Components
Part # Description
MS5145 Eclipse Scanner
00-02544 MetroSelect Single-Line Configuration Guide*
70-79016 MS5100 Eclipse Series User’s Guide*
* Manuals are available for download from www.honeywellaidc.com.
Optional Accessories
Part # Description
55-55000x-3
RS232 PowerLink Cable with Built-in Power Jack
straight cord, long strain relief, black
55-55002x-3
Keyboard Wedge PowerLink Cable with Adapter
straight cord, long strain relief, black
55-55020x-3
Stand Alone Keyboard PowerLink Cable,
straight cord, long strain relief, black
55-55235x-N-3
USB Low Speed Communication Cable, Type A
straight cord, long strain relief, black
55-55200x-N-3
USB Full Speed Cable, Locking Plus-Power™ Type A
straight cord, long strain relief, black
Note: This cable is for use with full speed USB (-40)
interface only.
MVC**
RS485 Applications,
MVC Cable, ±12VDC to +5.2VDC
** Contact a customer service representative for additional information on the MVC
cable series and the host connections available.
46-46633 Countertop Stand
Other items may be ordered for the specific protocol being used. To order additional items,
contact the dealer, distributor, or customer service. See page 35 for contact information.

Honeywell Eclipse MS5145 Specifications

General

Scan Pattern	Single Line
Light Source	650 nm visible laser diode
Scan Speed	72 scan lines per second
Interface	USB, RS232, Keyboard Wedge, IBM 46xx (RS485)
Weight	100 g (3.5 oz)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 60°C (-40°F to 140°F)
Humidity	5% to 95% relative humidity, non-condensing
Drop Resistance	Designed to withstand 1.5 m (5 ft) drops
Scan Rate	72 scan lines per second
Decode Capability	1D barcodes
Electrical Specifications	Input Voltage: 5 VDC ± 0.25 V
Regulatory Compliance	CE, FCC, RoHS
