Honeywell equIP H3W2GR1V - Page 87

Appendix A Technical Specifications
75
ELECTRICAL
POWER SUPPLY
PoE+(802.3at) Class 4/12VDC/AC24V
LONG DISTANCE POE SUPPORT
3X POE (300m @100Mbps)
AC FREQUENCY
50/60 Hz
POWER CONSUMPTION
HBW2GR3V: Max 17.3W ; HBW2GR1V: Max 20.5W
HBL2GR1V: Max 17W
AUXILIARY POWER SUPPLY
2.0W, DC12V (+/-5%)
MECHANICAL
DIMENSIONS
11.1 × 4.3 in. (281.0 × 110.0 mm)
WEIGHT
Product weight: 4.70lb (2130g)
Package Weight: 6.28lb (2847g)
CONSTRUCTION
Die-cast aluminum housing with powder coat
CONSTRUCTION COLOR
RAL 9003 (White) and RAL 7022 (Grey)
ENVIRONMENTAL
OPERATING TEMPERATURE
–40°F to 140°F (–40°C to 60°C)
RELATIVE HUMIDITY
0% to 95%, non-condensing
GORE VENTS
Yes
INGRESS PROTECTION
IP 67
IMPACT RESISTANCE
IK10
HEATER, FAN OPTION
Heater
REGULATORY
EMISSIONS
FCC Part 15, CE (EN 55032); Complies with RCM (AS/NZS)
IMMUNITY
CE (EN 50130-4)
SAFETY
North America UL Listed to UL/CSA 60950-1, CE (EN 60950-1); North
America UL Listed to UL/CSA 60950-22, CE (EN 60950-22)
ROHS
EN50581
