107062-12 EN FR26 GLO 501 Printed in France 27
FF-SB14 Series
Resolution: 35 mm (1.38 in)
FF- SB14E/R
!! ! - S 2
K = 120/240 Vac
1
4 = 24 Vdc to 48 Vdc
Nominal protected height
04 = 400 mm (15.75 in)
06 = 600 mm (23.62 in)
08 = 800 mm (31.50 in)
10 = 1000 mm (39.37 in)
12 = 1200 mm (47.24 in)
14 = 1400 mm (55.12 in)
Example: FF-SB14E/R08K-S2
FF-SB15 Series
Resolution: Perimeter Guarding (Body Detection) ONLY
FF- SB15E/R
!! !-S2
K = 120/240 Vac
1
4 = 24 Vdc to 48 Vdc
Nominal protected height
06 = 600 mm (23.62 in), 2 sets of beams
10 = 1000 mm (39.37 in), 3 sets of beams
14 = 1400 mm (55.12 in), 4 sets of beams
Example: FF-SB15E/R10K-S2
1
The unit automatically switches to the applied ac voltage level.
