107062-12 EN FR26 GLO 501 Printed in France 25
Specifications
OPERATING CHARACTERISTICS
Scanning Range FF-SB12 0 m to 10 m (0 ft to 32.8 ft.) for -S2 version
0 m to 6 m (0 ft to 19.7 ft.) for -S2F version and
FF-SB12E1R02E-S2
FF-SB14 0 m to 10 m (0 ft to 32.8 ft)
FF-SB15 3 m to 24 m (9.84 ft to 78.8 ft)
Object Detection Size FF-SB12 22 mm (0.87 in) minimum
FF-SB14 35 mm (1.38 in) minimum
FF-SB15 235 mm (9.25 in) minimum (body detection)
Angle of Divergence ± 2°
Emitting Light Source Infrared, pulsed, 880 nm
Immunity to Ambient Light sunlight 20,000 Lux
lamplight 15,000 Lux
ELECTRICAL CHARACTERISTICS
Supply Voltage (emitter or receiver) 120/240 Vac (+10 %, -20 %), 48 Hz to 62 Hz
24 Vdc to 48 Vdc*, ± 15 %,
Power Consumption (emitter or receiver) 8 Vac / 8 W dc
Output Type Mechanically-linked relay contacts
Output Switching Capability 50 mA min., 2 Amps at 250 Vac
1 Amp at 48 Vdc Max.
Test Input External dry contact required
Response Times FF-SB12 ≤ 29 msec
FF-SB14 ≤ 30 msec
FF-SB15 < 27 msec
Immunity to Electrical Noise IEC 1000-4-4 (Replaces IEC 801-4, Norm)
ENVIRONMENTAL/PHYSICAL CHARACTERISTICS
Operating Temperature Range 0 °C to 55 °C (32 °F to 131 °F)
Sealing NEMA 4, 13, and IP 65
Housing Dimension FF-SB12/FF-SB14 Width, 56 mm (2.2 in); Depth, 116 mm (4.6 in); Height**
FF-SB15
Width, 56 mm (2.2 in); Depth, 116 mm (4.6 in) Height 4
beam group, 1569 mm (61.77 in)
Height 3 beam group, 1169 mm (46.02 in)
Height 2 beam group, 769 mm (30.28 in)
Material Housing Aluminum Alloy
Front Plate Polycarbonate (FF-SB12, FF-SB14)
Polymethylmethacrylate (PMMA) (FF-SB15)
*The dc version is featured with a galvanic insulation (dc to dc converter) that provides the same level of immunity to
external disturbances as ac versions; this is essential to guarantee the safety integrity of the light curtain.
**Refer to the Unit Height Table for individual unit heights.
