28 107062-12 EN FR26 GLO 501 Printed in France
Mirror and Mounting Bracket Order Guide
Mounting Bracket Kit
(one kit is required for emitter, one kit is required for receiver)
Part Listings Description
FF-SBZS5000 Two omega shaped brackets with vibration dampeners and mounting accessories
FF-SBZS6000 Two "L" shaped brackets with vibration dampeners and mounting accessories
FF-SBZS7000A Two rotatable brackets with vibration dampeners and mounting accessories
FF-SBZS8000 Set of vibration dampeners and mounting accessories
(includes 8 screws + 8 nuts + 8 washers + 8 antivibration inserts)
FF-MPZS9018 Floor mounting post for mirror
FF-SBZS9010 Floor mounting column for FF-SB Series with protected height at 1000 mm or less, this listing includes a
FF-SBZS8000 set.
Mirrors
Part Listings Description
FF-SBSMIR02 One deflection mirror for use with the 200 mm protection height light curtain
FF-SBSMIR04 One deflection mirror for use with the 400 mm protection height light curtain
FF-SBSMIR06 One deflection mirror for use with the 600 mm protection height light curtain
FF-SBSMIR08 One deflection mirror for use with the 800 mm protection height light curtain
FF-SBSMIR10 One deflection mirror for use with the 1000 mm protection height light curtain
FF-SBSMIR12 One deflection mirror for use with the 1200 mm protection height light curtain
FF-SBSMIR14 One deflection mirror for use with the 1400 mm protection height light curtain
Replacement Part Order Guide
There are two versions of the FF-SB Series light curtains: the Original version and the CE version. Refer to
the appropriate replacement part table when ordering.
