FF-SB Light Curtains
Catalog Listing Serial Number
FF-SB12E/R . . . 5001→....
FF-SB14E/RxxK-S2 50001→....
FF-SB14E/Rxx4-S2 21001→....
FF-SB15 . . . 1001→....
FF-SB Replacement Parts
Part Listings Description
Relays
FF-SBZ132001 Removable 3 relay board for FF-SB Series except FF-SB12 200 mm
FF-SBZ132003 FF-SB CE removable 3 relay board filtered
FF-SBZ0110020 Two safety relays for FF-SB12E/R02E-S2
Fuses
FF-SBZ109001 Box of 10 fuses 0,25 A / Time delay for SB12E/R02❏-S2❏
FF-SBZ109002 Box of 10 fuses 0,5 A time delay for FF-SB
Plugs
FF-SBZ1721201 Female supply plug for emitter or receiver
FF-SBZ1721136 Female signal plug for receiver
FF-SBZ1721137 Plug-female supply metal plug emitter FF-SB/K-S
FF-SBZ1721202 Plug-female supply metal plug receiver FF-SB/K-S
Other Spare Parts
FF-SBZ0130010 Set of 8 Torx screws for FF-SB
FF-SBZ172115 Kit of 100 female crimping contacts for DIN 43652 metal connector
FF-SBZ666144* Kit of reducer and câble glands for a complete set FF-SB*
FF-SBZROD22 ø22 mm test rod for FF-SB12 Series
FF-SBZROD35 ø35 mm test rod for FF-SB14 and FF-SB15 series
FF-SBZ0140010 Torx screw driver ac x 20
FF-SBZCRIMP Crimping tool for FF-SB connectors
FF-SBZREMOV Removal tool for FF-SB connectors
FF-SBZSERV1 1
st
level maintenance kit for FF-SB series
Transparent front plates
FF-SBZ0100050 2 transparent front plates for emitter and receiver for FF-SB12 series H = 200 mm
FF-SBZ0100010 2 transparent front plates for emitter and receiver for FF-SB12/14 series H = 400 mm
FF-SBZ0100020 2 transparent front plates for emitter and receiver for FF-SB12/14 series H = 600 mm
FF-SBZ0100030 2 transparent front plates for emitter and receiver for FFSB14 series H = 800 mm
FF-SBZ0100040 2 transparent front plates for emitter and receiver for FF-SB14 series H = 1000 mm
FF-SBZ0100060 2 transparent front plates for emitter and receiver for FF-SB14 series H = 1200 mm
FF-SBZ0100070 2 transparent front plates for emitter and receiver for FF-SB14 series H = 1400 mm
FF-SBZ01506 2 front plates for one FF-SB15E/R06❑-S2 set
FF-SBZ01510 2 front plates for one FF-SB15E/R10❑-S2 set
FF-SBZ01514 2 front plates for one FF-SB15E/R14❑ -S2 set
Special front plates
FF-SBZFL40❑❑ 1 special optical filter (shock-proof, improve immunity to light interference. Reduces scanning
ranges by 40 %. For receiver only)
Nominal protected height (ex: FF-SBZFL4006 to be fixed on a receiver unit)
FF-SBZFL00❑❑ 1 shock-proof transparent front plate (order 2 for a complete set emitter and receiver)
Nominal protected height (ex: FF-SBZFL0006 plates)
*The kit FF-SBZ666144 includes:
• For the emitter plug: PG9: allowed cable diameters: 5 mm to 8,7 mm / 0,2 in to 0.34 in
• For the receiver plug: PG13: allowed cable diameters : 8,5 mm to 13,5 mm / 0.33 in to 0.53 in
PG21: allowed cable diameters: 11 mm to 19 mm / 0.44 in to 0.74 in
Reducer PG21/PG13
Reducer PG21/PG9
