26 107062-12 EN FR26 GLO 501 Printed in France
Light Curtain Order Guide
Catalog listings for the FF-SB Series light curtains include: one emitter, one receiver, two mating plugs for the
metal quick-disconnect connectors, two arc suppressors, one test rod, and this installation manual.
The three safety relays R1, R2, and R3, the cycle start push-button, and the test contacts (shown in the wiring
diagram in Chapter 3) must be supplied by the customer. Mounting brackets, accessories, and mirrors must
be ordered separately.
Each set of mounting brackets includes the following hardware: bolts, nuts, washers, and vibration
dampeners. For a typical light curtain installation, two sets of mounting brackets are necessary; one for the
emitter and one for the receiver. An emitter or receiver may require different types of mounting brackets in
certain applications.
If the light curtains are mounted directly to a machine, order the mounting accessories set (FF-SBZS8000).
Mirrors are supplied with mounting brackets and accessories.
FF-SB12 Series
Resolution: 22 mm (0.86 in)
FF- SB12E/R
! ! ! - S2
G = 240 Vac only (unit size = 200 mm)
K = 120/240 Vac
1
(unit size > 200 mm)
E = 120 Vac only (unit size = 200 mm)
4 = 24-48 Vdc
Nominal protected height
02 = 200 mm (7.87 in)
04 = 400 mm (15.75 in)
06 = 600 mm (23.62 in)
Example: FF-SB12E/R04K-S2
1
The unit automatically switches to the applied ac voltage level.
