74 107062-12 EN FR26 GLO 501 Printed in France
Front Window Plate Replacement
1200 and 1400 mm protected height FF-SB Series Light Curtain emitters and receivers have a black part
located in the middle of the transparent front plate that must be removed during front plate removal.
1. Ensure you have the following tools and spare parts: 1 #20 Torx driver, 2 to 4 joiner clamps (2 for
2.
FF-SB14 400 mm, 4 for FB-SB14 1400 mm), 2 wooden battens (30 mm x 30 mm for example), spare
front plates with gaskets.
3. Remove the power supply and optical controller modules as described in the previous sections.
4. Remove the end cover and pull off the two plastic caps on each end of this piece.
5. Depress both sides of the plate and remove the black piece by pushing it to one side.
6. Depress the transparent front window plate with the clamp, inserting wooden battens between clamps
and the safety light curtain.
7. Remove the two pressing rods by pushing them (for 1200 and 1400 mm, pull the rods with a screw).
8. Remove front window plate and gasket.
9. Install the new gasket. Glue point of the gasket in the middle of the height of the light curtains (ease
tension on gasket).
10. Hold gasket and allow the new front window plate to slide in the housing (sticker inside).
11. Press the front window plate with the clamps and replace the pressing rods.
12. Replace end cover and the electronic boards.
13. Perform an operational test to ensure proper functional readiness.
