Installation Guide and Operating Manual
Honeywell 21
4.2 Product Variations
There are product variations above and beyond those that are field selectable by the end user(s). These
variations are provided for the customer that has specialized needs.
Here is a list of current ordering options for the Model FS24X and FS24X-9:
Model - # # # - # # #
EXAMPLES:
FS24X-911-211
QuadBand Triple IR Detector, 90° Field of View, General Applications with Relays, 4-20mA Output,
FireBusII, Aluminum Enclosure with ¾ inch NPT Conduit Entries, Approvals: FM, cFM, ATEX,
IECEx: Class I, Division 1, Groups A, B, C & D; Class II, Division 1 Groups E, F & G; Class III;
Class I, Zone 1 AEx d/Ex d IIC Hazardous Locations: ATEX/IECEx
Class I, Zone 1, Ex db IIC (T4-T6) and Ex tb IIIC (T4-T6).
FS24X-211-221
QuadBand Triple IR Detector, 110° Filed of View, General Applications with Relays, 4-20mA
Output, FireBusII, 316 Stainless Steel Enclosure with ¾ inch NPT Conduit Entries, FM, cFM,
ATEX,IECEx: Class I, Division 1, Groups A, B, C & D; Class II, Division 1 Groups E, F & G; Class
III; Class I, Zone 1 AEx d/Ex d IIC Hazardous Locations: ATEX/IECEx Class I, Zone 1, Ex db IIC
(T4-T6) and Ex tb IIIC (T4-T6).
Model Numbers
FS24X
Outputs
1 = Relays / 4-20mA / FireBus II / Modbus
2 = Relays / HART Communication
Application
1 = General Applications
Manufacturer’s Code
2 = Standard Honeywell Analytics Detector - 110° Field of View (-1 has been replaced by -2)
9 = Standard Honeywell Analytics Detector - 90° Field of View
Enclosure Types
10 = No Enclosure (Module Only)
21 = Aluminum, ¾” NPT Conduit Entries
22 = 316 Stainless Steel ¾” NPT Conduit Entries
23 = Aluminum, 25 mm Conduit Entries
24 = 316 Stainless Steel 25 mm Conduit Entries
Approvals1 = not available
2 = FM, cFM (Class I, Divisions 1 & 2)
3 = FM, cFM, ATEX, IECEx (Class I, Zone 1)
4 = INMETRO
5 = not available
6 = BRE (EN54-10)
7 = CCCF
8 = GOST (CUTR)
-
