Codes [42, Quick Menu 7] Galaxy Flex Installer Manual
58
3. Press
to start the self-learn process. The message User Awaiting Fob is displayed.
4. On the keyfob, press both SOS buttons (buttons 1 and 3) together.
If successful, the message Fob learned is displayed for 3 seconds.
If no device is detected within 30 seconds, the message Self Learn Timed Out is
displayed.
5. If required, and if the feature is available, select 1=Enabled to enable the Panic
function on the keyfob.
Note: In some regions this feature may be disabled.
If the keyfob does not learn:
1. Remove the battery.
2. Short circuit the battery terminals.
3. Replace the battery and repeat the above procedure.
To enable the panic function on an existing keyfob:
Note: Enable [51.60.2] before selecting this option.
1. Select 2=Fob PA, and then press ent.
2. Select 1=Enabled.
Card Users [42.2]
This option determines the tags/cards on the system for various users. There are seven
options:
Add Batch [42.2.1]
Use this option to start enrolment and display the user/tag for each presentation. When batch
enrolling (auto assigning of tags to users), the panel increments the user number starting
from Batch Start. It does this for every new tag presented at the DCM assigned in Batch
DCM.
Test Batch [42.2.2]
Use this option to check the stored tag number with the tag presented at the Batch DCM. It
can also be used to go directly to the user programming details that are assigned to the tag
presented.
Delete Batch [42.2.3]
Use this option to remove card numbers from enrolment. A warning is given before deletion.
Batch Start [42.2.4]
Use this option to determine the user number at which enrolment starts.
