Description
HON 380 gas pressure regulator with HON 673/674 controller 15
2.6 Technical specifications
Components Material
Valve body
Cast steel
SAV
Aluminum cast alloy and aluminum
wrought alloy
Casing of actuator
Steel plate / aluminum alloy
Diaphragms; gaskets
NBR
Internal parts
Aluminum alloy, steel, brass
Criterion Value
Max. inlet pressure p
umax
20 bar
Temperature range
-20 to +60 °C
(-4 to +140 °F)
There are various flange facings for the nominal diameters of 1" (DN 25),
2" (DN 50), 3" (DN 80), and 4” (DN 100) as specified in the following standards:
 ASME B16.5
Pressure rating as per Class 150 = 20 bar
Flange facing: Raised face
 DIN EN 1092-1
Pressure rating as per PN 16 = 16 bar
Flange facing: B flange
Materials
Environmental condi-
tions
Pressure rating and
flange facing stand-
ards
