Installation and Operation
7
3 Installation and Operation
Panel Description
Front Panel
Please refer to following figure for the front panel view and Table
3-1 for front panel interfaces.
Figure 3-1 Front Panel
Table 3-1 Front panel interfaces
No. Name No. Name
1 USB interface (two) 2 On/Off Button
3
KB-LK keyboard
indicator
4 HDD indicator
5 Power indicator 6 Reset
7 KB-LK keyboard switch
