Fire Alarm Control Panel IQ8Control C/M
FB 798951.GB0 / 01.09 113
* 3 relay module/3 relay module CF
Analog
channel
Function
Normal value range FACP
IQ8Control
Ana 1 Relay 1 93 ... 141
Ana 2 Relay 2 93 ... 141
Ana 3 Relay 3 93 ... 141
Ana 4 Not occupied 00
Ana 5 Not occupied 00
* Ana 1 ... Ana 3 = "0" in the case of inverse, unmonitored or activated relays
* Master box activation module
Analog
channel
Function
Normal value range FACP
IQ8Control
Ana 1
Monitoring input 50 to 300 Ohm
301 to 1000 Ohm
27...100
35...150
Ana 2 Not occupied 00
Ana 3 Not occupied 00
Ana 4 Not occupied 00
Ana 5 Not occupied 00
* Ana 1 = “0” in the case of activated transmission device
* Analog loop module
Analog
channel
Function
Normal value range FACP
IQ8Control
Ana 1 Emergency mode monitoring, module 00 ... 27
Ana 2 Not occupied 00
Ana 3 Not occupied 00
Ana 4 Not occupied 00
Ana 5 Not occupied 00
* Ana 1 = “0” if module is not in emergency mode
