Honeywell IQ8Control C User Manual

Fire Alarm Control Panel IQ8Control C/M
FB 798951.GB0 / 01.09 59
IQ8Control C
The Field device module with a single micro module slot (Part No. 772478) must be placed on the >System
connector 1< of the Basic module. This connector is normally used by the Field device module. Without the field
device module a system configuration in accordance to the standards is not possible (refer to section „Panel
configuration IQ8Control C“).
IQ8Control M
Up to two connectors are available for Extension modules (Field device and or Extension module). Normally the
lower >connector 2< is used to connect an Extension module. If required the upper >connector 1< may be used
too for an Extension module. In this case the integration of an Field device module is impossible. In this case
mounting of the field device is not possible anymore (refer to section „Panel configuration IQ8Control C“).
Extension module with a single micro module slot (Part No. 772478)
This Extension module must be configured in the panels data programming as a Field device module.
connector
>System connector 1 or 2< of the Basic modules
Refer to note!
X 1a/2b/3c
Connector for a micro module
(Do not connect an essernet
®
micro module)
X11a/12b
Terminals for the micro module wiring (refer to the I-text at the bottom)
X 10
Extension module with three micro module slots (Part No.772476)
Only FACP IQ8Control M configurable.
ON – Common fire alarm
LED V1
ON – CPU failure
LED V2
Micro module slot only for micro module
place 1
Micro module slot only for micro module
place 2
Micro module slot only for micro module
Do not connect an
essernet
®
micro module,
Refer to note!
place 3
terminal for micro module slot 1
X22
terminal for micro module slot 2
X23
terminal for micro module slot 3
X24
Plug contact of
>System connector 1 or 2< of the Basic module
Refer to note!
X 4/5/6
If an essernet
®
micro module is installed, this module can only be operated on the micro module
slot of the Basic module.
4.4.1 Technical Data Extension module
Operating voltage : Internal via the power supply module, +5 V DC
Quiescent current : approx. 10 mA
: max. 1,5 mm
2
wire gauge, removable Terminals
Compatibility : Part No.772478
Î Extension module with one micro module slot
Part No.772476
Î Extension module with three micro module slots
