Fire Alarm Control Panel IQ8Control C/M
FB 798951.GB0 / 01.09 33
4.1.4 Specification Power supply module (Part No. 802426)
Main voltage : 230 V AC (+10% / -15%),
Rated current : 0,7 A
Rated frequency range : 50 to 60 Hz (ref. to nameplate)
Rated frequency : 50 Hz
Output voltage : 12 V DC
Current for ext. devices : max. 2A
Permissible current consumption with
2 x 24 Ah batteries and 72 hour
emergency power supply
: max. 650 mA
Battery capacity : max. 2 x 12 V DC / 24 Ah (= 48 Ah)
Battery charge voltage
Undervoltage protection
:
:
13,65 V DC @ 25 °C
9,5 V DC (with jumper BR2 switch-on / off)
Ambient temperature : -5 °C to +45°C
Storage temperature : -5 °C to +50°C
Ambient conditions : class 3k5 according to DIN EN 60721-3-3
Protection class : I according to DIN EN 6050
Compatibility : Part No. 802426 Index G or higher
The power supply module is suited for the Fire Alarm Control
Panels IQ8Control C/M with the required Basic module (Part No.
772481/-82).
The required loop voltage (27,5 V or 42 V for esserbus
®
PLus)
must be selected on the power supply module with jumper BR4!
For IQ8Control C/M fire alarm control panels it is possible to use
the power supply module from hardware version Index G as a
replacement module. Pay attention to the settings on the power
supply module of FACP IQ8Control C/M and the Index of the
hardware that is used!
Damage to the system!
Before connecting the alternating voltage (230V AC) read the
panel’s identification plate. It is not
permitted to connect a voltage
other than that shown on the identification plate (sticker in the
panel housing).
