Fire Alarm Control Panel IQ8Control C/M
FB 798951.GB0 / 01.09
5
1 Installation Instruction
Operation of the Fire Alarm Control Panel IQ8Control is governed by the national version of the operating
system software used and the country version programmed in the customer data. The terminal assignment and
wiring illustrated in these installation instructions refer exclusively to the facilities of the operating system
software for the Federal Republic of Germany
D
.
The fire alarm panel may only be installed in a dry, clean room with controlled access and appropriate
lighting. The environmental conditions must comply with DIN EN 60721-3-3, class 3k5.
The panel must be mounted on a flat surface using appropriate hardware (screws and dowels). Avoid
mechanical stressing. It may only be commissioned after correct mounting on a wall or other mounting
surface of sufficient strength to support the weight of the unit.
Avoid strong electric or magnetic fields as well as mechanical influences. This applies especially to the
presence of fluorescent lighting or energy cabling in the close vicinity of the panel, its components and the
associated cabling. Do not mount on vibrating, unstable surfaces such as light partitioning walls.
Do not install the system in places where adverse conditions prevail. Parts and components of the system
may only be installed in or led through locations which allow compliance with DIN VDE 0800.
Control panels and visual indicators mounted on a wall should be installed at a height of 800 to 1800 mm
above the floor.
The fire alarm system is not suitable for connection to IT power supply systems.
It is highly recommended for correct ESD protection that the dummy plug (factory supplement) of the
programming interface plug is inserted into the front of the operation panel.
This documentation applies to the following products:
Fire Alarm Control Panel IQ8Control C/M
Standard system software (without special customer-dependent functionality)
Country function >Germany<
Configuration and Commissioning
For the configuration and commissioning of the system, the programming software tools 8000 is required in
each case in the current program version.
Installer / Installation Specialist
The fire alarm control panel must be installed by a skilled electrician (according to DIN VDE 0833), who, as a
result of the appropriate training and experience, can evaluate the work to be carried out and recognise
potential dangers. In addition to the specialist qualifications, knowledge of the validity and application of the
relevant standards and their use and compliance with is required.
Operator of the Fire Alarm System / Trained Person
For the operation of the fire alarm control panel, a qualified person must be trained in the basic functioning of
the system and its technical requirements. A trained person (according to DIN VDE 0833) must be able to
operate the fire alarm control panel and to recognise faults. If a fault signal occurs or the functionality is limited,
arrangements must be made for the checking and rectification of the cause of the fault.
Maintenance / Service
Maintenance is necessary for the proper operation of the fire alarm control panel. The function of the system
parts can be affected by environmental conditions and ageing. For an application within the area of validity of
the European Union (EU) the maintenance is defined in EN 54. In addition to the safety directives and notes in
this documentation, the country-specific requirements for the operational location of the fire alarm control panel
must be observed.
