Fire Alarm Control Panel IQ8Control C/M
4 FB 798951.GB0 / 01.09
7
Master box activation module ................................................................................................................................. 87
7.1 Technical Data Master box activation module (Part No. 784385) ................................................................. 91
8 Installer level............................................................................................................................................................. 96
9 Diagnostic display .................................................................................................................................................. 108
9.1 Diagnostic display IQ8Control C/M ................................................................................................................ 108
10 Meaning of the three digit error codes / test mode.............................................................................................. 115
11 Functionality for fire alarm control panels............................................................................................................. 126
11.1.1 Use of the analog loop module in door control systems.................................................... 126
12 IQ8Wireless devices.............................................................................................................................................. 127
13 Top hat rail mounting kit (Part No. 788652) ......................................................................................................... 129
14 esserbus
®
transponder.......................................................................................................................................... 131
15 Extension housing.................................................................................................................................................. 132
15.1 Extension housing for two batteries (Part No. 789300 / -01)................................................................... 134
16 Power supply for the built-in printer ...................................................................................................................... 135
17 Mounting / Replacing of the Panel front + Printer................................................................................................ 136
17.1 Heat transfer Printer without paper take-up unit (Part No. 7868xx / 7869xx)........................................ 136
17.2 Printer with paper take-up reel (Part No. 7863xx) .................................................................................... 139
18 Fire protection housing (F30)................................................................................................................................ 141
Danger – Electrical shock !
Remove all power from the panel before carrying out any installation work!
ESD protection
While handling electronic assemblies, the necessary precautions against electrostatic discharge
must be taken.
Protective and functional earth
The PE conductor must be connected to the corresponding terminal at the mains supply. Connect
the FE terminal of the panel’s cabinet with the PE rail of the power distributor panel from which the
fire alarm system will be powered.
Commissioning
A complete system check must be carried out after commissioning and for each modification of the
customer data programming!
Additional and updated Informations
The described features, specifications and product related informations in this manual correspond
to the date of issue (refer to date on the front page) and may differ due to modifications and/or
amended Standards and Regulations of the System design, Installation and Commissioning.
Updated informations and declaration of conformity are available for comparison on the
www.esser-systems.de homepage.
esserbus
®
and essernet
®
are registered trademarks in Germany.
