Honeywell IQ8Control C User Manual

Fire Alarm Control Panel IQ8Control C/M
FB 798951.GB0 / 01.09 131
14 esserbus
®
transponder
esserbus
®
transponders are input/output modules for extending the control panel inputs/outputs. As devices on
the analog loop - the esserbus
®
- they may be operated jointly in separate detector zones with fire detectors on
the esserbus
®
.
It is possible to install up to 32 esserbus
®
transponders in separate detector zones (separated by zone
isolators). Mixing the operation of fire detectors and esserbus
®
transponders is not permissible within one
detector zone.
The esserbus
®
transponders is installed either at special fitting locations or on a standard C-mounting rail in the
Fire Alarm Control Panel, or at decentralised level at any location in a special plastic housing (Part No. 788600 /
788601). The internal voltage supply is fed to the esserbus
®
transponder from the zone voltage of the analog
loop.
For additional information refer to the technical manual of the esserbus
®
transponder.
Type Description Part No.
eK-12REL with 12 relay outputs 808610.10
eK-32AE with 32 outputs to drive LED 808611.10
eK-1Grp with one detector zone input 808614.10
with 4 detector zone inputs and 2 relay outputs 808613.20 eK-4Grp/2Rel
To be operated as standard interface (SST) to control
extinguishing systems
808613.30
eK-KOM-LMST communications transponder for a 8010 fire alarm and
extinguishing computer.
808615
This communications transponder is installed inside the
housing and immediately on the processor board of the 8010
fire alarm and extinguishing computer.
eK-FSA The FSA-transponder for a stand-alone fire door control or as a
loop device connected fire alarm system 8000.
808619.10
Third party module Third party module RZT 8000 for an individual connection of
automatic and non-automatic fire alarm detectors supplied by
other manufacturers
80863X.10
For esserbus
®
PLus loops with a loop voltage of 42 V it is required to connect the appropriate
transponders or devices with the Part No. 80xxx x (refer to Chapter 5.1.2).
