Honeywell IQ8Control C User Manual

Fire Alarm Control Panel IQ8Control C/M
58 FB 798951.GB0 / 01.09
4.4 Extension module
Depending on the module type up to three slots for micro modules are integrated on the Extension module.
Connections are available for each micro module. The pin assignment of the eight screw terminals depends on
the employed type of micro module. The pin assignment of the connectors is described for each micro module.
MM2
1
8
Extension module 772478
X3c X2b X1a
X 10
X11a X12b
Fig.52: Extension module (Part No.772478) with one micro module slot
12345678 12345678 12345678
Place 1
Extension module 772476
Place 2
Place 3
V2
V1
X 22
X 23 X 24
X 6 X 5 X 4
Place 1 Place 2 Place 3
Fig.53: Extension module (Part No.772476) with three micro module slots (only IQ8Control M)
