Fire Alarm Control Panel IQ8Control C/M
122 FB 798951.GB0 / 01.09
Trouble
text
Possible cause 1st. measure 2nd. measure
start-up
An error has been detected
when an analog loop was
switched on; normal operation
is impossible.
Localise the source with
programming software tools
8000 switch on or reconfigure
the analog loop.
---
Detector >
When an analog loop was
switched on, more detectors
were found than programmed
in the customer data or more
detectors were found in an
EDD detector zone than
programmed in the customer
data.
Localise the source with
programming software tools
8000, switch on or reconfigure
the analog loop For EDD
detector zones, check the
number of detectors and
reprogram the customer data
if necessary.
---
Detector <
When an analog loop was
switched on, fewer detectors
were found than programmed
in the customer data.
Localise the source with
programming software tools
8000, switch on or reconfigure
the analog loop.
---
Topolog.
The wiring configuration of this
analog loop cannot be
precisely determined.
Localise the source with
programming software tools
8000, switch on or reconfigure
the analog loop.
---
Serial No
A detector has been found in
the corresponding analog loop
which is not programmed in
the customer data.
Have detectors been
exchanged and is the error
plausible?
If yes, execute the Exchange
detector function for this
analog loop to update data.
Line A
The 1st ring is inoperable in a
redundant essernet
®
wiring.
The 2nd ring is in operation.
Check essernet
®
wiring
Check the essernet
®
switchover module and
replace if necessary.
Line B
The 1st ring is inoperable in
redundant essernet
®
wiring.
Check essernet
®
wiring
Check switch over module
and replace if necessary.
AD conv.
Fault of the A/D converter
card on the Basic module or
the A/D converter of the
analog loop module is
defective.
Replace Basic module or
micro module.
---
