Fire Alarm Control Panel IQ8Control C/M
FB 798951.GB0 / 01.09 133
The extension housing is assembled similar to the central housing. The individual assembly steps are described
in the section "Assembling the central housing".
The following must also be observed when assembling the extension housing:
The connection pieces between the central and extension housings can be pushed into the housing only
from the rear side due to the door hinge. If an extension housing is fitted at the bottom
to an already
securely installed central housing, the central housing must be removed from the assembly surface.
A separate drilling template is available for each of the two housing variants with the standard or battery
rear panel. The drilling template is enclosed in the central unit’s additional pack.
The fastening holes in the mounting surface must be drilled precisely and without offset to the side.
Otherwise, use of the connecting pieces between the two housings is no longer possible in the event of
major deviations.
If the extension housing with the battery rear panel is used, please note that depending on the
rechargeable batteries used, a significant weight must be supported by the fastening screws of the
extension housing. Longer 8 mm flat-head screws should always be used here.
Each housing must be separately secured with suitable fastening materials such as screws and
dowels. Attachment of the extension housing with fastening only via the connection pieces between
the central and extension housing is not permissible.
Rear panel extension options
The standard rear panel may be used in combination with the extension housing (Part No. 789302/03) to install
additional components. Holes E and H are provided for mounting the various components. The standard rear
panel allows the following extensions:
6 esserbus
®
transponders, Part No. 808613.20, 808613.30 or 808614.10 (mounting holes E)
or
4 esserbus
®
transponders, Part No. 808610.10 or 808611.10 (holes H)
or
3 esserbus
®
transponders, Part No. 808613.20, 808613.30 or 808614.10 (holes E) and
2 esserbus
®
transponders, Part No. 808610.10 or 808611.10 (holes H)
