Honeywell IQ8Control C User Manual

Fire Alarm Control Panel IQ8Control C/M
38 FB 798951.GB0 / 01.09
1. Open panel housing
2. Set DIL switch S2 (1+2) on the Basic module in Pos. ON (LED V50 lits).
3. Press reset button
Î FACP reset
4. Wait until FACP is resetted and the display message „Servicemode“ appears.
5. Connect USB cable (Part No. 789863) to the USB-connector of the FACP IQ8Control an.
6. Start tools 8000 software on the Service PC and select >Tools / actualize panel software<.
7. After the firmware update the message >Update successful< appears on the Service-PC
8. Remove USB-plug from the Basic module and set DIL-switch in position OFF
Î the FACP IQ8Control will
be automatically resetted and returns to the normal operation mode.

Honeywell IQ8Control C Specifications

General

Brand	Honeywell
Model	IQ8Control C
Category	Control Panel
Language	English
