Honeywell Midas User Manual

Midas
®
Gas Detector
15-2
15 Ordering information
This section contains details of how to order complete Midas
®
detector and sensor cartridge kits, separate
transmitters and sensor cartridges as well as spares and accessories.
Item Description Part No.
Midas
®
Transmitter
Midas
®
transmitter. Complete with manual and quick start guide. (1) PG16 gland
fitting for power in and relays out, 1/4” O.D. x 1/8” I.D. sample inlet tubing (10’) [3m],
3/16” I.D. exhaust tubing (10’) [3m], and a sample line tubing duct adapter. Order a
sensor cartridge separately for each transmitter.
MIDAS-T-004
Midas
®
Pyrolyzer
for NF
3
Midas
®
NF
3
Pyrolyzer Module. Pyrolyzer in combination with Midas
®
transmitters
provide detection of NF
3
specifically. Unit includes a bolt-on pyrolyzer module that
operates with and universal Midas
®
Extractive Transmitter (order separately) and (1)
Freon in line filter. Units are powered via direct connection to transmitter unit. Consult
Honeywell Analytics for additional gases that may become available via pyrolysis.
Pyrolyzer includes Pyrolyzer Quick Start Guide and installation screws. Order the NF
3
cartridge (MIDAS-S-HFX or MIDAS-E-HFX) separately. Order the ventilated top cover
(MIDAS-A-039) separately.
MIDAS-T-00P
Midas
®
High-
Temperature
Pyrolyzer
for Perfluoro
Compounds
Midas
®
PFC (Perfluoro Compound) Pyrolyzer Module. PFC Pyrolyzer in combination
with Midas
®
transmitters provide detection of various PFC compounds including C
4
F
6
,
C
5
F
8
, CH
2
F
2
and CH
3
F. Unit includes a bolt-on pyrolyzer module that operates with
any Universal Midas
®
Extractive Transmitter (order separately). Units are powered
via direct connection to transmitter unit. Consult Honeywell Analytics for additional
gases detectable with this option. Pyrolyzer includes Pyrolyzer Quick Start Guide
and installation screws. Order the PFC cartridge (MIDAS-S-CFX or MIDAS-E-CFX)
separately. Order the ventilated top cover (MIDAS-A-039) separately.
MIDAS-T-HTP
Midas NP1
Pyrolyzer for NF3
and Perfluoro
Compounds
Midas® NF3 and PFC Pyrolyzer Module. This Pyrolyzer in combination with Midas®
transmitters provide detection of NF3 and various PFC compounds including C4F6,
C5F8, CH2F2 and CH3F. Unit includes a bolt-on pyrolyzer module that operates with
any Universal Midas® Extractive Transmitter (order separately). Units are powered
via direct connection to transmitter unit. Consult Honeywell Analytics for additional
gases detectable with this option. Pyrolyzer includes Pyrolyzer Quick Start Guide and
installation screws. Order the sensor cartridge separately (MIDAS-S-XHF or MIDAS-E-
XHF for NF3 and CH3F; MIDAS-S-XCF or MIDAS-E-XCF for C4F6, C5F8, and CH2F2).
MIDAS-T-NP1
Midas
®
LonWorks
®
Module
Midas
®
LonWorks
®
Interface Module. Option for use with connecting a Midas
®
transmitter or a transmitter with pyrolyzer, to a LonWorks
®
life safety communications
network. Module provides all communication and power to the MIDAS
®
transmitter
and transmits all gas readings, faults, alarms and other sensor diagnostics via the
LonWorks
®
protocol. Access to LonMaker
®
version 3.1 configuration software is
required (available separately).
MIDAS-T-LON

Honeywell Midas Specifications

General

Power Supply	24 VDC
Detection Technology	Electrochemical, Infrared
Sampling Method	Diffusion
Display	LCD
Communication	Modbus RTU, 4-20mA
Operating Temperature	-20°C to +50°C
Humidity Range	0% to 95% RH (non-condensing)
Target Gas	Multiple gases
Response Time	< 30 seconds
Operating Humidity	0% to 95% RH (non-condensing)
Outputs	4-20mA
Protection Rating	IP66
Certifications	ATEX, UL, CSA
Detection Gases	Oxygen (O2), Carbon Monoxide (CO), Hydrogen Sulfide (H2S), Methane (CH4), and others
