ID2000 Series Operating Manual
Operator Actions at Panel
22997-434-000-4, Issue 4
May 2010
4.8.4.1 Individual VIEW Sensor
To recalibrate an individual VIEW sensor:
1 Press ‘0’. The panel display changes as shown below:
2 Select the VIEW sensor in the same way as any other
individual sensor. The prompt shown below is
displayed:
3 Answer to complete the operation (remember that
the VIEW sensor will be inoperative for the next 60
seconds after this step). The action is logged and if a
printer is installed the message ‘sensor replaced’ is
printed out.
4.8.4.2 Loop of VIEW Sensors
To recalibrate a loop of VIEW sensors:
1 Press ‘1’. The panel displays the prompt shown below:
2 Enter the loop number. The panel then displays one
of the prompts shown below (depending upon whether
ALL loops or a single loop is specified):
3 Press
to complete the operation. Sensors will be
inoperative for the next 60 seconds. The action is
logged in memory and to the printer if fitted.
Loop number (1-n; 0=ALL):
Select replaced sensor:
Choose from ZONE no.: (0=ALL)?0
Has sensor been replaced (
!!
!!
!/X)?
All sensors replaced, this loop (
!!
!!
!/X)?
All sensors replaced (
!!
!!
!/X)?
