52 LDM Series Instruction Manual — P/N 15885:H3 8/12/2019
AFP-100 (UL 8th) Configuration for the LDM-32 and AFP-100
Alarm and Trouble Mode Without 8-Point Shift
LDM-32s set to address 1 with expanders support control switches. LDM-32s set to addresses other than 1 do not support control
switches.
Alarm and Trouble Mode With 8-Point Shift
It is assumed that systems with 8-Point Shift selected will be 56 zones or less.
Table D.1 LDM Series Switch Control Functions
LDM Switch
Position
LDM-32 1st LDM-E32 2nd LDM-E32 3rd LDM-E32
1 ACK not used not used not used
2 SIG.SIL. not used not used not used
3 RESET not used not used not used
4 DRILL not used not used not used
5 not used not used not used not used
6 not used not used not used not used
7 not used not used not used not used
8 not used not used not used not used
9 not used not used not used not used
10 not used not used not used not used
11 not used not used not used not used
12 not used not used not used not used
13 not used not used not used not used
14 not used not used not used not used
15 not used not used not used not used
16 not used not used not used not used
LDM Switch Position LDM-32 1st LDM-E32 2nd LDM-E32 3rd LDM-E32
1 not used not used not used not used
2 not used not used not used not used
3 not used not used not used not used
4 not used not used not used not used
5 not used not used not used not used
6 not used not used not used not used
7 not used not used not used not used
8 not used not used not used not used
9 not used not used not used ACK
10 not used not used not used SIG.SIL.
11 not used not used not used RESET
12 not used not used not used DRILL
13 not used not used not used not used
14 not used not used not used not used
15 not used not used not used not used
16 not used not used not used not used
