LDM Series Instruction Manual — P/N 15885:H3 8/12/2019 55
Configuration for the LDM-32 and AFP-100 AFP-100 (UL 8th)
Alarm/Trouble Annunciation of Points
The table below illustrates the configuration of the LDM Series modules to annunciate the alarm and trouble states for all 198 points
(detectors and modules) with the first eight points of address ‘01’ dedicated to the AFP-100 system functions.
Detectors
Set addresses ‘01’ and ‘02’ for detectors.
Modules
Set addresses ‘03’ and ‘04’ for modules.
Alarm/Trouble Annunciation of Points - With 8-Point Shift
The table below illustrates the configuration of the LDM Series modules to annunciate the alarm and trouble states for all 198 points
(detectors and modules) with the last eight points of address ‘01’ dedicated to the AFP-100 system functions.
Detectors
Set addresses ‘01’ and ‘02’ for detectors.
LDM Module
Address ‘01’
LDM Output Connectors
J5 J6 J7 J8
LDM-32 System Functions 1 to 4 5 to 8
1st LDM-E32 9 to 12 13 to 16 17 to 20 21 to 24
2nd LDM-E32 25 to 28 29 to 32 33 to 36 37 to 40
3rd LDM-E32 41 to 44 45 to 48 49 to 52 53 to 56
LDM Module
Address ‘02’
LDM Output Connectors
J5 J6 J7 J8
LDM-32 57 to 60 61 to 64 65 to 68 69 to 72
1st LDM-E32 73 to 76 77 to 80 81 to 84 85 to 88
2nd LDM-E32 89 to 92 93 to 96 97 to 99 Not used
Table D.2 Alarm/Trouble Setup - Detectors - without 8-Point Shift
LDM Module
Address ‘03’
LDM Output Connectors
J5 J6 J7 J8
ADT-LDM-32 1 to 4 5 to 8 9 to 12 13 to 16
1st LDM-E32 17 to 20 21 to 24 25 to 28 29 to 32
2nd LDM-E32 33 to 36 37 to 40 41 to 44 45 to 48
3rd LDM-E32 49 to 52 53 to 56 57 to 60 61 to 64
LDM Module
Address ‘04’
LDM Output Connectors
J5 J6 J7 J8
ADT-LDM-32 65 to 68 69 to 72 73 to 76 77 to 80
1st LDM-E32 81 to 84 85 to 88 89 to 92 93 to 96
2nd LDM-E32 97 to 99 Not used Not used Not used
Table D.3 Alarm/Trouble Setup - Modules - without 8-Point Shift
LDM Module
Address ‘01’
LDM Output Connectors
J5 J6 J7 J8
LDM-32 1 to 4 5 to 8 9 to 12 13 to 16
1st LDM-E32 17 to 20 21 to 24 25 to 28 29 to 32
2nd LDM-E32 33 to 36 37 to 40 41 to 44 45 to 48
3rd LDM-E32 49 to 52 53 to 56 System Functions
LDM Module
Address ‘02’
LDM Output Connectors
J5 J6 J7 J8
LDM-32 57 to 60 61 to 64 65 to 68 69 to 72
1st LDM-E32 73 to 76 77 to 80 81 to 84 85 to 88
Table D.4 Alarm/Trouble Setup - Detectors - with 8-Point Shift
