56 LDM Series Instruction Manual — P/N 15885:H3 8/12/2019
AFP-100 (UL 8th) Configuration for the LDM-32 and AFP-100
Modules
Set address ‘03 and ‘04’ for modules.
Alarm Only Annunciation of Points
The table below illustrates the configuration of the LDM Series modules to annunciate the alarm state of all 198 points (detectors and
modules) with the first eight points of address ‘01’ dedicated to the AFP-100 system functions.
Detectors
Set address ‘01’ and ‘02’ for detectors.
Modules
Set address ‘03’ and ‘04’ for modules.
Alarm Only Annunciation of Points - With 8-Point Shift
The table below illustrates the configuration of the LDM Series modules to annunciate the alarm state of all 198 points (detectors and
modules) with the last eight points of address ‘01’ dedicated to the AFP-100 system functions.
2nd LDM-E32 89 to 92 93 to 96 97 to 99 Not used
LDM Module
Address ‘03’
LDM Output Connectors
J5 J6 J7 J8
LDM-32 1 to 4 5 to 8 9 to 12 13 to 16
1st LDM-E32 17 to 20 21 to 24 25 to 28 29 to 32
2nd LDM-E32 33 to 36 37 to 40 41 to 44 45 to 48
3rd LDM-E32 49 to 52 53 to 56 57 to 60 61 to 64
LDM Module
Address ‘04’
LDM Output Connectors
J5 J6 J7 J8
LDM-32 65 to 68 69 to 72 73 to 76 77 to 80
1st LDM-E32 81 to 84 85 to 88 89 to 92 93 to 96
2nd LDM-E32 97 to 99 Not used Not used Not used
Table D.5 Alarm/Trouble Setup - Modules - with 8-Point Shift
LDM Module
Address ‘01’
LDM Output Connectors
J5 J6 J7 J8
LDM-32 System Functions 1 to 8 9 to 16 17 to 24
LDM-E32 25 to 32 33 to 40 41 to 48 49 to 56
LDM Module
Address ‘02’
LDM Output Connectors
J5 J6 J7 J8
LDM-32 57 to 64 65 to 72 73 to 80 81 to 88
LDM-E32 89 to 96 97 to 99 Not used Not used
Table D.6 Alarm Only Setup - Detectors
LDM Module
Address ‘03’
LDM Output Connectors
J5 J6 J7 J8
LDM-32 1 to 8 9 to 16 17 to 24 25 to 32
LDM-E32 33 to 40 41 to 48 49 to 56 57 to 64
LDM Module
Address ‘04’
LDM Output Connectors
J5 J6 J7 J8
LDM-32 65 to 72 73 to 80 81 to 88 89 to 96
LDM-E32 97 to 99 Not used Not used Not used
Table D.7 Alarm Only Setup - Modules
LDM Module
Address ‘02’
LDM Output Connectors
J5 J6 J7 J8
Table D.4 Alarm/Trouble Setup - Detectors - with 8-Point Shift
