NFS2-640 Operations P/N 52743:L4 06/10/19 49
Viewing and Printing a Read Status Read Status Operation
See page 42 and 43 of the NFS2 640 Programming Manual.
Figure 4.10 System Function Selection 5 Screen
See page 44 of the NFS2 640 Programming Manual.
Figure 4.11 System Function Selection 6 Screen
See Page 42 of the NFS2 640 Programming Manual.
Figure 4.12 System Function Selection 7 Screen
• SEC_RLY and SUP_RLY (0= turn on by Fire Alarm, 1= turn on by Security, 2= turn on by
Supervisory).
• BAT_SIZE (1= battery size is greater than 26 Ahr, 0= less than 26 Ahr).
• C_DRILL (custom drill N= No custom drill, Y= Yes).
• TERM_DATA (0= LCD80 Terminal using 7 bit data, 1= LCD80 Terminal using 8 bit data).
• PRT_BAND (0= 2400, 1= 4800, 2= 9600).
Figure 4.13 System Function Selection 8 Screen
NOTE: Please refer to the VeriFire Tools help file for information on programming the above
screen.
REGION=0 TBL.REMIND=2 ALA.SCROLL=Y
LOCAL CONTROL=1 IP ACCESS=0 DCC-MODE=N
S5
FLASHSCAN LIDET LIMOD L2DET L2MOD
Y Y Y Y
S6
NODE: 000.XXX, CLASSX:N
THRESHOLD CHANNEL A:H, CHANNEL B:H
S7
SEC_RLY:1 SUP_RLY:2 BAT_SIZE:0 C_DRILL:N
TERM_DATA:0 PRT_BAUD:2 CHARGER:Y
S8
