50 NFS2-640 Operations P/N 52743:L4 06/10/19
Read Status Operation Viewing and Printing a Read Status
An Annunciator Selection screen shows the information that will display on the ACS annunciators.
The table above contains the ACS display selections. Annunciators set to annunciator address 1 to
19 can be programmed to any one of the above selections. If t here is a UDACT or UDACT-2,
selections A-M will be sent to Annunciator addresses 20 to 32 respectively.
An example of ACS selections in Annunciator Selection Screen 1:
Figure 4.14 Annunciator Selection Screen 1 Example
NOTE: An ACS selection marked with an asterisk (*) indicates no annunciator selection.
The figure above shows annunciator selections for addresses A1-A2 (addresses A3-A10, marked
with asterisks, are not selected).
• Annunciators set to annunciator address 1 (A1) display the status of detectors 1-64 on SLC 1
(ACS Selection Group H)
• Annunciators set to annunciator address 2 (A2) display the status of intelligent modules 1-64
on SLC-1 (ACS Selection Group C).
1 through 9 Programmable Annunciator #1 through #9
0 Programmable Annunciator #10
A 8 Systems points + Zones 1-56
B Zones 57-99, 9 F zones, 8 R zones, 4NAC
C Loop 1, Modules 1-64
D Loop 2, Modules 1-64
E Loop 1, Modules 65-128
F Loop 2, Modules 65-128
G Loop 1, Modules 129-159 & Loop 2, Modules 129-159
H Loop 1, Detectors 1-64
I Loop 2, Detectors 1-64
J Loop 1, Detectors 65-128
K Loop 2, Detectors 65-128
L Loop 1, Detectors 129-159 & Loop 2, Detectors 129-159
M Programmable for use with FireVoice NFV-25/50ZS
N 8 Systems points + Zones 1-56, used for remote station communicator (TM-4)
O 8 Systems points + Zones 1-56, used for municipal box trip output (TM-4)
P Loop 1, Modules 65-100, Loop 1, Detectors 1-14 (Detector Maintenance
Reporting)
Q Loop 2, modules 65-100, Loop 2, Detectors 1-14 (Detector Maintenance
Reporting)
R Loop 1, detectors 15-46 (Detector Maintenance Reporting)
S Loop 2, Detectors 15-46 (Detector Maintenance Reporting)
T Loop 1 Detectors 47-78 (Detector Maintenance Reporting)
U Loop 2, Detectors 47-78 (Detector Maintenance Reporting)
V Loop 1, Detectors 79-100 (Detector Maintenance Reporting)
W Loop 2, Detectors 79-100 (Detector Maintenance Reporting)
Annunciator addresses 1 to 19 can be programmed to any one of the above selections. If there is a UDACT
or UDACT-2, selections A-M will be sent to Annunciator addresses 20 to 32 respectively.
Table 4.2 ACS Selection Groups (2 of 2)
ANNUN SELECTION: A1=H A2=C A3=* A4=*
A5=* A6=* A7=* A8=* A9=* A1-=* A11=*
